LinkStar meets the needs of Internet Service Providers operating in densely populated cities or small rural communities with GPON solutions that are reliable and scalable

  • LSM1300 GPON OLT
  • The LSM1300 GPON OLT is designed for large Internet service providers in mind. It has a highly integrated design with the ability to support more than 16,000 ONTs in a 10U chassis. The 80Gbps uplink interface to core network allows the operator to enjoy greater scalability when provisioning bandwidth for each user.

  • Supports 16,384 ONTs
  • Maximum of 256 GPON ports
  • 10U chassis
  • 80Gbps uplink interface
  • Compatible with
    10G GPON (XGPON) cards
  • Full redundancy for power,
    switch and uplink cards
  • LSM1320 GPON OLT
  • LSM1320 GPON OLT is suitable for smaller service providers providing fiber broadband access to areas where population density is low. Available in a compact size, this power saving OLT supports more than 2000 ONTs.

  • Supports 2048 ONTs
  • Maximum of 32 GPON ports
  • Hot swappable switch card
  • Load balancing for switch card
  • 24Gbps uplink interface
  • Dual power supply design
  • 2U chassis with low power consumption
  • GPON ONT designed for cost and energy efficiency, LinkStar’s family of ONTs can be deployed in a wide range of applications including residential and business FTTH. There is a wide range of port configurations available for different use cases.

  • Wide range of port configurations
  • 1 to 4 Gigabit Ethernet ports
  • IEEE 802.11n wireless
  • POTS port based on SIP
  • Low power consumption
  • TR-069 management
  • Optional RF video port for CATV
  • Coexistence with 10G PON
  • Battery back-up option


  • Our MDUs operate silently and offer PoE functionality for remotely powering end devices such as IP surveillance cameras and wireless access points.

  • 8, 16, or 24 Ethernet ports
  • Up to 24 POTS ports
  • PoE and PoE+ options available
  • Fanless design for quiet operation
  • Low power consumption
  • DC Power backup
